BV421 Streptavidin
BV421 Streptavidin
Flow cytometric analysis of CD45R/B220 expression on mouse lymphocytes.  BALB/c mouse splenic leucocytes were stained with Biotin Rat Anti-Mouse CD45R/B220 antibody (Cat. No. 553085/553086) followed by BD Horizon™ BV421 Streptavidin/SAV (Cat. No. 563259; solid line histogram) or with BD Horizon™ BV421 Streptavidin alone (dashed line histogram). Flow cytometric histograms were derived from gated events with the forward and side light-scatter characteristics of viable lymphocytes. Flow cytometry was performed using a BD™ LSRII System.
BV421 Streptavidin
Immunohistofluorescent analysis of CD45R/B220 expression by cells within C57BL/6 mouse spleen. A mouse spleen cryosection (5 µm) was fixed with BD Cytofix™ Fixation Buffer (Cat. No. 554655) and blocked with 5% goat serum and 1% BSA diluted in 1x PBS. The sections were then treated with an Avidin/Biotin Blocking Kit (Vector Laboratories), and stained with Alexa Fluor® 488 Rat Anti-Mouse CD4 antibody (Cat. No. 557667, pseudo-colored blue), Alexa Fluor® 647 Rat Anti-Mouse CD8a antibody (Cat. No. 557682, pseudo-colored red), and Biotin Rat Anti-Mouse CD45R/B220 antibody (Cat. No. 553085). After washing, sections were then stained with BD Horizon™ BV421 Streptavidin secondary reagent (Cat. No. 563259, pseudo-colored green). Images were captured on a standard epifluorescence microscope. Original magnification, 20x.
Flow cytometric analysis of CD45R/B220 expression on mouse lymphocytes.  BALB/c mouse splenic leucocytes were stained with Biotin Rat Anti-Mouse CD45R/B220 antibody (Cat. No. 553085/553086) followed by BD Horizon™ BV421 Streptavidin/SAV (Cat. No. 563259; solid line histogram) or with BD Horizon™ BV421 Streptavidin alone (dashed line histogram). Flow cytometric histograms were derived from gated events with the forward and side light-scatter characteristics of viable lymphocytes. Flow cytometry was performed using a BD™ LSRII System.
Immunohistofluorescent analysis of CD45R/B220 expression by cells within C57BL/6 mouse spleen. A mouse spleen cryosection (5 µm) was fixed with BD Cytofix™ Fixation Buffer (Cat. No. 554655) and blocked with 5% goat serum and 1% BSA diluted in 1x PBS. The sections were then treated with an Avidin/Biotin Blocking Kit (Vector Laboratories), and stained with Alexa Fluor® 488 Rat Anti-Mouse CD4 antibody (Cat. No. 557667, pseudo-colored blue), Alexa Fluor® 647 Rat Anti-Mouse CD8a antibody (Cat. No. 557682, pseudo-colored red), and Biotin Rat Anti-Mouse CD45R/B220 antibody (Cat. No. 553085). After washing, sections were then stained with BD Horizon™ BV421 Streptavidin secondary reagent (Cat. No. 563259, pseudo-colored green). Images were captured on a standard epifluorescence microscope. Original magnification, 20x.
Product Details
Down Arrow Up Arrow


BD Horizon™
Flow cytometry (Routinely Tested), Immunocytochemistry, Immunofluorescence (Tested During Development)
0.1 mg/ml
AB_2869475
Aqueous buffered solution containing BSA and ≤0.09% sodium azide.
RUO


Preparation And Storage

Store undiluted at 4°C and protected from prolonged exposure to light. Do not freeze. Streptavidin was conjugated with dye under optimum conditions, and unconjugated Streptavidin and free dye were removed

Recommended Assay Procedures

BD™ CompBeads can be used as surrogates to assess fluorescence spillover (Compensation).  When fluorochrome conjugated antibodies are bound to CompBeads, they have spectral properties very similar to cells.   However, for some fluorochromes there can be small differences in spectral emissions compared to cells, resulting in spillover values that differ when compared to biological controls.  It is strongly recommended that when using a reagent for the first time, users compare the spillover on cells and CompBead to ensure that BD Comp beads are appropriate for your specific cellular application.

For optimal and reproducible results, BD Horizon Brilliant Stain Buffer should be used anytime two or more BD Horizon Brilliant dyes are used in the same experiment.  Fluorescent dye interactions may cause staining artifacts which may affect data interpretation.  The BD Horizon Brilliant Stain Buffer was designed to minimize these interactions.  More information can be found in the Technical Data Sheet of the BD Horizon Brilliant Stain Buffer (Cat. No. 563794/566349) or the BD Horizon Brilliant Stain Buffer Plus (Cat. No. 566385).

Product Notices

  1. Since applications vary, each investigator should titrate the reagent to obtain optimal results.
  2. Caution: Sodium azide yields highly toxic hydrazoic acid under acidic conditions. Dilute azide compounds in running water before discarding to avoid accumulation of potentially explosive deposits in plumbing.
  3. Source of all serum proteins is from USDA inspected abattoirs located in the United States.
  4. Pacific Blue™ is a trademark of Molecular Probes, Inc., Eugene, OR.
  5. For fluorochrome spectra and suitable instrument settings, please refer to our Multicolor Flow Cytometry web page at www.bdbiosciences.com/colors.
  6. BD Horizon Brilliant Violet 421 is covered by one or more of the following US patents: 8,158,444; 8,362,193; 8,575,303; 8,354,239.
  7. BD Horizon Brilliant Stain Buffer is covered by one or more of the following US patents: 8,110,673; 8,158,444; 8,575,303; 8,354,239.
  8. Alexa Fluor® is a registered trademark of Molecular Probes, Inc., Eugene, OR.
  9. Please refer to http://regdocs.bd.com to access safety data sheets (SDS).
  10. Please refer to www.bdbiosciences.com/us/s/resources for technical protocols.
563259 Rev. 4
Antibody Details
Down Arrow Up Arrow

BD Horizon™ BV421 Streptavidin is a useful second-step reagent for the indirect immunofluorescent staining of cells in combination with biotinylated primary antibodies for flow cytometric analysis.

Streptavidin is a non-glycosylated protein that is prepared chromatographically from the bacterium Streptomyces avidinii. Streptavidin homotetramers have a particularly high, non-covalent binding affinity for biotin. When conjugated with fluorochromes, streptavidin has been widely used with biotin-conjugated antibodies and other biotinylated specific-binding molecules (eg, recombinant proteins and lectins) to stain cells and tissues for subsequent multiparameter analysis by flow cytometry, fluorescence microscopy and imaging. Likewise, when conjugated with an enzyme (eg, Horseradish Peroxidase or Alkaline Phosphatase) and coupled with a colorimetric or luminescent substrate development system, streptavidin has found widespread use along with biotinylated antibodies in a number of applications including Western blot, ELISA, ELISPOT, immunocytochemistry and immunohistochemistry.

Streptavidin was conjugated to BD Horizon BV421 which is part of the BD Horizon Brilliant™ Violet family of dyes. With an Ex Max near 407 nm and Em Max near 421 nm, BD Horizon BV421 can be excited by the violet laser (405 nm) and detected with a 450/50 nm filter. BD Horizon BV421 conjugates are very bright, often exhibiting a 10 fold improvement in brightness compared to Pacific BlueTM conjugates. Due to nearly identical excitation and emission properties but different spillover characteristics, BD Horizon BV421, Pacific Blue, and BD Horizon V450 cannot be used simultaneously.

563259 Rev. 4
Format Details
Down Arrow Up Arrow
BV421
The BD Horizon Brilliant Violet™ 421 (BV421) Dye is part of the BD Horizon Brilliant Violet™ family of dyes. This polymer-technology based dye has an excitation maximum (Ex Max) of 407-nm and an emission maximum (Em Max) at 423-nm. Driven by BD innovation, BV421 is designed to be excited by the violet laser (405-nm) and detected using an optical filter centered near 420-nm (e.g., a 431/28-nm or 450/50-nm bandpass filter). BV421 is an ideal alternative for V450 as it is approximately ten times brighter with less spillover into the BV510/V500 detector. Please ensure that your instrument’s configurations (lasers and optical filters) are appropriate for this dye.
altImg
BV421
Violet 405 nm
407 nm
423 nm
563259 Rev.4
Citations & References
Down Arrow Up Arrow
View product citations for antibody "563259" on CiteAb

Development References (2)

  1. Diamandis EP, Christopoulos TK. The biotin-(strept)avidin system: principles and applications in biotechnology. Clin Chem. 1991; 37(5):625-636. (Biology). View Reference
  2. Shapiro HM. Practical flow cytometry, 4th ed.. Hoboken, N.J.: Wiley-Liss; 2003:1-681.
563259 Rev. 4



Please refer to Support Documents for Quality Certificates


Global - Refer to manufacturer's instructions for use and related User Manuals and Technical data sheets before using this products as described


Comparisons, where applicable, are made against older BD Technology, manual methods or are general performance claims.  Comparisons are not made against non-BD technologies, unless otherwise noted.

For Research Use Only. Not for use in diagnostic or therapeutic procedures.
